Painted Steel Utility Pressure Gauge 40mm 300 PSI Manometer Bar

Brand Name : WESEN or Customized

Model Number : M04.02.040.B

Certification : CE, ISO

Place of Origin : China

MOQ : 100 Pieces

Price : Negotiable

Payment Terms : T/T

Supply Ability : 20000 Pieces per Month

Delivery Time : 3~4 Weeks

Packaging Details : Carton

Deaign : EN837-1

Size : 40mm

Mount : Panel Mount

Pressure Range : 300 psi or Customized

Case Material : Painted Steel

Lens Material : Acrylic

Bourton Tube : Phosphor Bronze

Movement : Brass

Dial : Aluminum

Accuracy : 2.5

Contact Now

40mm Pressure Gauge Manufacturer 300 PSI Manometer Bar

Description

The pressure gauge has a dial size 40mm, the case of the gauge comes from black painted steel, and the connection and bourdon tube are made by brass. The pressure range of the gauge is 300 psi. And the gauge has a dual scale kPa & psi.

Applications

For gaseous and liquid media that are not highly viscous or crystallising and will not attack copper alloy parts.

Pneumatics

Heating and air-conditioning technology

Medical engineering

Special features

Reliable and cost-effective

Design per EN 837-1

Nominal size 40, 50, 63, 80, 100 and 160

Scale ranges up to 0 ... 400 bar

Specifications

Design

EN 837-1

Nominal size

 40mm

Accuracy

 2.5
Pressure range 300 psi (customized)

Pressure limitation

Steady: 3/4 x full scale value
Fluctuating: 2/3 x full scale value
Short time: full scale value

Permissible temperature

Ambient: -20 ... +60 °C
Medium: +60 °C maximum

Temperature effect

When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of the span

Process connection

 Brass

Pressure element

 Brass, C-type or helical type

Bourdon tube
Movement Brass
Dial Aluminium, white, with pointer stop pin
Black/red lettering
Pointer Aluminium
Case Painted Steel
Window Acrylic
Options

Other process connection
Surface mounting flange
Mounting bracket

Dimensions

lower mount (radial)

Painted Steel Utility Pressure Gauge 40mm 300 PSI Manometer Bar

Dial Size Dimensions in mm Weight in kg
a b D G h SW
40 9.5 26 39 G1/4 36 14 0.08
50 10 27.5 49 G1/4 45 14 0.10
63 9.5 27.5 62 G1/4 53.5 14 0.13
80 11.5 30 79 G1/2 72 22 0.18
100 11.5 30.5 99 G1/2 83.5 22 0.21
160 15.5 42 160 G1/2 115.5 22 0.85

back mount (axial)

Painted Steel Utility Pressure Gauge 40mm 300 PSI Manometer Bar

Dial Size Dimensions in mm Weight in kg
b1 b2 D G SW
40 26 42 39 G1/8 14 0.06
50 29.5 47.5 49 G1/4 14 0.07
63 29 47 62 G1/4 14 0.08
80 32 49 79 G1/4 14 0.11
100 31 49 99 G1/4 14 0.26

Ordering information

Model / Dial size / Pressure Range / Process connection / Options

Painted Steel Utility Pressure Gauge 40mm 300 PSI Manometer Bar
