Brand Name : WESEN or Customized
Model Number : M01.02.040.N
Certification : CE, ISO
Place of Origin : China
MOQ : 100 Pieces
Price : Negotiable
Payment Terms : T/T
Supply Ability : 20000 Pieces per Month
Delivery Time : 3~4 Weeks
Packaging Details : Carton
Size : 40mm
Mount : Axial
Pressure Range : 100 MPa
Color : White
Case Material : Stainless Steel
Lens : PC glass
Movement : Copper alloy
Thread : 1/8" or 1/4" PT, NPT, G, BSP
Accuracy : 2.5
Bracket : U-Clamp
40mm Stainless Steel Case Pressure Gauge 100 psi Axial Mount Manometer Acc 2.5 with U Clamp
Description
This pressure gauge has a very concise dial plate, black lettering with white background. Black pointer with stop pin. The U-clamp helps the pressure gauge easily to be installed on the panels.
Applications
Injection Molding Device, Hydraulic
Machine building and plant construction
Heating and air-conditioning technology
Fire sprinkler systems
Special features
Design per EN 837-1
Nominal size 40, 50, 63, 80, 100 and 160
Scale ranges up to 0 ... 1000 bar
Design | EN 837-1 |
Nominal size | 40mm |
Accuracy | 2.5 |
Pressure range | 100 psi (customized) |
Pressure limitation | Steady: 3/4 x full scale value |
Permissible temperature | Ambient: -40 ... +60 °C |
Temperature effect | When the temperature of the measuring system deviates from the reference temperature (+20 °C): max. ±0.4 %/10 K of full scale |
Process connection | Brass |
Pressure element | Bourdon tube, brass |
Movement | Copper alloy |
Dial | Aluminium, white, with pointer stop pin Black lettering |
Pointer | Aluminium |
Case | Stainless steel |
Window | Plastic, glass |
Options | Other process connection thread |
Ordering information
Model / Dial size / Pressure Range / Process connection / Options
![]() |
